OD5.2MM 1+4 20 24AWG 5 Wire Medical AED Coiled Cable Defibrillator Cable

Defibrillator Coil & Defibrillator Wire Defibrillator wires have 3 main forms:Coil & Round;Straight & Round and Flat Ribbon.The most used is Coil cord for AED paddle,and Flat Ribbon cable for AED Pad.

The Defibrillator cable usually contains 3 to 10 depends on its purpose and applications. A simple 3 wire defibrillator (it could be a aed training machine) only need 3 wires for the paddle. And ECG Defibrillator will use 4-8 signal wire to get ECG signal,indicates the operator if it is necessary to make difibrillation and when to make it. The more Intelligent a ECG Monitor with defibrillator is,the more wires it need.ECG Defibrillator monitor the heart and indicates the operator when is the best time to defibrilate and how many joules power is needed.It make defibrillation easier and more accurate.

As a China Medical cable manufacturer ,we custom AED cable ( AED leads) to interconnect between its power unit and the patient paddle or Pads according to customer‘s requirement

AED electrode pads become a mainstream,compared with Paddles,AED Pads/Gel are used to reduce transthoracic impedance when paddles are applied directly to the chest wall to deliver a shock. Better protective for patients and doctors. Especially with Mindray intellectual AED, an un-trained person can also make an emergency rescue under the guide of the defibrillators’ screen and voice AED Cable has 1 or 2 17AWG-22 AWG wires can bear 5000V AC voltage and 3-8 wires for Signals transition.Round Coiled Extension cord and Flat Bulk Cable are the two main forms.

Coiled Extension cord for Defibirllator adopts TPU as Jacket. As for insulation,when extreme high voltage such as 8000V AC ,is needed,and also need the cable to be thin,then Teflon (FEP,PFA PTFE) is used.
