8 Core Multifunctional combination cable Medical Transducer Cable
Technical Specification
| Items | Specification | ||
| Products name | |||
| Model | TR208S | ||
| Conductor | Material | Tinned copper+Nylon*4C | Tinned copper+Nylon*2P |
| Specification | 19/0.O8TC+250D Nylon | 19/0.12TC+250D Nylon | |
| Insulation | Material | PP | PP |
| Nom.Thickness | 0.14 | 0.24 | |
| Nom.O.D. | ø0.70士0.05 | ø1.1士0.05 | |
| Colour | White/Green/Yellow/Blue | Red/Black,Gray/Orange | |
| Isolation | Material | Aluminum leaf | |
| Shield | Material | Tinned copper | Tinned copper |
| Specification | 60士3/0.08TC | 72士3/0.08TC | |
| Coverage | >94% | >94% | |
| Inner Jacket | Material | 80A-PVC(White) | |
| Nom.O.D. | ø2.5士0.10 | ||
| Nom.Thickness | 0.18 | ||
| Filler | Material | Cotton Thread | |
| Wrap | Material | Cotton Tissue | |
| Jacket | Material | TPE | |
| Nom.Thickness | 1.1 | ||
| Nom.O.D. | ø7.5士0.15 | ||
| Colour | Gray | ||
